Spesifikasi Turbosound TPX153 3-Way Dual 15" Performer Series Full Range Loudspeaker

Turbosound TPX153 3-Way Dual 15" Performer Series Full Range Loudspeaker

The three-way full range TPX153 is a passive dual 15" 2000 Watt loudspeaker system that is ideally suited for a wide range of portable speech and music sound reinforcement, including FOH, side and drum fill applications. Engineered as a standalone three-way system not requiring any external equalization or filtering, the TPX153 achieves optimal performance when paired with a subwoofer and TURBOSOUND loudspeaker management systems.

The TPX153 loudspeaker features dual high excursion 15" low frequency drivers with low mass voice coils for improved transient response, and an aluminum dome 1" compression driver mounted on a 70° horizontal by 50° vertical dispersion low distortion waveguide. All drivers are matched with an internal passive crossover network in a reflex-loaded enclosure.

Covered in black carpet, the cabinet is constructed of 18 mm (¾ ") plywood and includes a rugged powder coated perforated steel mesh grille backed with reticulated foam, and durable handles for easy transport. The rear panel connector plate carries Neutrik speakON* NL4 connectors for input and link connections to additional enclosures.

LF drivers with low mass coil for improved transient response
Aluminium dome 1" compression driver with extended HF reproduction
Rugged carpet-covered 18mm (3/4") wood construction
Powder coated perforated steel mesh grille
Durable handles for easy lifting and carrying
Neutrik speakON* NL4 connectors for reliable long life operation
Designed and engineered in England

Speaker configuration

• Active/passive: Passive
• Type: Full-range
• LF driver: 2 x 15"
• MF driver: Not applicable
• HF driver: 1" Titanium dome

Power capacity

• 8 Ohms program/peak:
• 4 Ohms program/peak: 500W Cont/2000W Peak

Audio

• Frequency response: 50Hz - 20kHz +3dB
• Coverage pattern: 70° x 50°
• Max SPL: 124 dB cont

Inputs

• TRS: Not applicable
• TS: Not applicable
• RCA: Not applicable
• SPEAKON: 1

Output/thru

• TRS: Not applicable
• TS: Not applicable
• RCA: Not applicable
• SPEAKON: 1

Enclosure

• Cabinet material: 18 mm birch ply
• Width: 18.1"
• Height: 42.9"
• Depth: 16.9"
• Weight: 84.9 lb.
