Spesifikasi Celestion K12H-200TC 12" 200 Watt Full-Range Professional Woofer Driver 8 Ohm
Celestion K12H-200TC 12" 200 Watt Full-Range Professional Woofer Driver 8 Ohm
Celestion's K12H-200TC 8 ohm 12" full range driver is an excellent choice when space is at an absolute minimum. This driver uses a dual cone, or whizzer cone, design improving the high frequency response well beyond that of a standard 12", eliminating the need for a tweeter and crossover. The primary cone handles low to midrange frequencies while the smaller secondary cone reproduces the higher frequencies. A pressure formed cloth dust cap reinforces the secondary cone for enhanced mid-band clarity.
Specs
- Nominal Diameter............................................12"
- Power Handling (RMS).................................200 Watts
- Power Handling (max)..................................400 Watts
- Impedance...................................................8 ohms
- Frequency Response....................................50 to 10,000 Hz
- Sensitivity.....................................................98 dB 1W/1m
- Voice Coil Diameter.......................................2"
- Magnet Weight..............................................50 oz.
- Product Dimensions.......................................13.39 x 6.3 x 12.99 inches;
- Weight...........................................................4.440669 Kgs
-
Mounting Information
- Overall Outside Diameter.......................................12.2"
- Baffle Cutout Diameter...........................................11.14"
- Depth....................................................................5.14"
- Bolt Circle Diameter...............................................11.75"
- # Mounting Holes...................................................4
-
Materials of Construction
- Cone Material..............................................Paper / KevlarSurround
- Material.......................................................Cloth
- Voice Coil Wire Material...............................Copper
- Voice Coil Former........................................Kapton® / Polyimide
- Basket / Frame Material...............................Steel
- Magnet Material...........................................Ferrite
