Biema P45 Speaker Pasif Karaoke Power Amplifier

Spesifikasi Biema P45 Speaker Pasif Karaoke Power Amplifier

Biema P45 Speaker Pasif Karaoke Power Amplifier

The soft start limiter will immediately shut down the output drive in overload or short circuit conditions, which ensures the reliability of the amplifiers. Stylish in appearance, the P series amplifiers are prefect to be installed in those commercial applications such as pubs, night clubs, mobile DJS, KTV, cinemas and sporting venues.
Stylish design as well as rugged heavy duty construction.
Soft start limiter.
XLR inputs.
Binding post & 4 pin speaker connectors.
Clipping & overload protect indicators.
Efficient cooling design.
Earth lift switch.
Standard 19" rack mounting.

Model
P45
Output power STEREO 8
2x450W
TA 1KHz THD0.1% 4
2x650W
Frequency response
10Hz-50KHz -1.5dB
Input sensitivity
0.77V/32dB
Input impedance active balanced
20K
Signal/ noise ratio a-weighted RMS
>95dB
Crosstalk at rated output power 8 ohm 1khz
>70dB
Damping factor f=1khz 8 ohms
>150
Slew rate internal
35V/s
Protection
SHORT CIRCUIT,OVER CURRENT,OVER HEAT
Indicators
POWER(BLUE) CLIP(RED) PROT(YELLOW)
Cooling
SMART FAN
Front panel controls
EVEL ACH, BCH, POWER SWITCH
Rear panel controls
GROUND/LIFT SWITCH
Connector
6.35MM INPUT,XLR INPUT, PROFESSIONAL SPEAKON OUTPUT,PROFE
SSIONAL BINDING POSTS OUTPUT
Power consumption half power 8 ohms
600W
Power supply
AC 200V-240V/50Hz
Product/ shipping dimensions(WDH)mm
482x430x88(585x560x145)mm
N.W/G.W
13.2kg/15.2kg
