Spesifikasi Yamaha EMX5014C 14 Channel 1000W Powered Mixer

Yamaha EMX5014C 14 Channel 1000W Powered Mixer

When sound reinforcement requirements get serious but you still want the convenience and reliability of a Yamaha powered mixer, the console-style EMX5014C is the ticket. It's an all-in-one solution that will appeal to gigging combos and venue operators alike. It provides a surprising palette of features and versatile signal routing options. And it's a Yamaha, so it's going to sound great.

Yamaha EMX5014C Powered Mixer Features:

• Exclusive single-knob compressors on each input control unruly vocals or tighten up a bass guitar
• Feedback channel locator LEDs on each input pinpoint problems for easy correction
• 80Hz highpass filters for eliminating low-frequency noise and rumble
• Channel ON switches let you switch individual channels into or out of the mix
• PFL (Pre-Fader Listen) switches allow isolated monitoring of individual channels
• All input channels feature signal and peak indicators for visual signal monitoring
• Linear Aux 1, Aux 2, and Effect return faders with AFL (After-Fader Listen) monitor switches
• Stereo master fader with both PFL and AFL monitor switches
• has been activated due to power amplifier overload
• Power amp mode selector allows 2-channel power amp to be quickly configured for Main + Main, Mono + Aux 1, or Aux 1 + Aux 2 operation
• Power amplifier output selector allows selection of 500, 200, or 75-watt output per channel

•

• Tech Specs

• Type:Powered
• Channels:14
• Power:350W @ 8 ohms, 500W @ 4 ohms
• Inputs - Mic Preamps:6 x XLR (CH 1-6), 2 x XLR (CH 7-10 Stereo)
• Inputs - Line:6 x 1/4" (CH 1-6), 4 x 1/4" (CH 7-10, Stereo), 4 x 1/4"(CH 11-14, Stereo, RCA)
• Outputs - Main:2 x speakON, 2 x 1/4", 2 x 1/4"
• Outputs - Other:2 x RCA (Tape), 2 x 1/4" (ST Sub)
• Headphones:1 x 1/4"
• Send/Return I/O:2 x 1/4" (Aux), 1 x 1/4" (Effects)
• Phantom Power:8 x Channels
• EQ Bands:3-band Sweepable Mid (Channels), 3-band (Stereo), 9-band Graphic (Main)
• Aux Sends:1 x Pre, 1 x Pre/Post
• Faders:14 x 60mm
• Channel Inserts:Yes (CH 1-6)
• Effects:Yes (Global and Compression on Channels 1-6)
• Rackmountable:Yes
• Height:6.13"
• Depth:19.5"
• Width:17.5"
• Weight:23 lbs.
