Roland Blues Cube Tour Guitar Amplifier

Spesifikasi Roland Blues Cube Tour Guitar Amplifier

Roland Blues Cube Tour Guitar Amplifier

Driven by Roland’s acclaimed Tube Logic design, the Blues Cube Tour brings punch, presence, and authority to your backline. The flagship Tour head packs 100 big watts to provide ample power and headroom for concert-level performing, while the companion Blues Cube Cabinet410 cabinet delivers clear, wide-range sound with smooth highs and rich low end. Equipped with four custom 10-inch speakers, the Cabinet410 gives you the classic 4x10 open-back configuration of sought-after vintage combos, but in a convenient standalone cab with reduced size and weight. And thanks to its variable power control, Line Out, and USB connectivity, the Blues Cube Tour is equally suited for tracking in the studio, whether you want to mic up or go direct.

Going far beyond modeling, Roland’s Tube Logic design philosophy starts with carefully reproducing the inner workings of the revered tweed-era tube amp in every way, from guitar input to speaker output. Versatile clean and crunch channels can be used independently or combined for a complex range of tones, while variable output power modes let you dial in burning, full-throttle sound at any volume. Road-tested and fine-tuned with feedback from top players, the gig-ready Blues Cube delivers the sweet, magical tone and satisfying feel that makes a great guitar amp a highly expressive musical instrument.

Specifications

Rated Power Output

100 W

Nominal Input Level

INPUT HIGH: -10 dBu (1 M ohm)
INPUT LOW: 0 dBu
EFX LOOP A RETURN: -10 dBu
EFX LOOP B RETURN: -10 dBu

Controls

POWER switch
DUAL TONE switch
CH SELECT switch

[CLEAN channel]

BOOST button
TONE button
VOLUME knob

[CLEAN channel EQUALIZER]

BASS knob
MIDDLE knob
TREBLE knob

[CRUNCH channel]

BOOST button
TONE button
GAIN knob
VOLUME knob

[CRUNCH channel EQUALIZER]

BASS knob
MIDDLE knob
TREBLE knob

[EFFECT]

EFX LOOP A button
EFX LOOP B button
REVERB knob

[MASTER]

PRESENCE knob
MASTER knob
POWER CONTROL switch
0.5 W, 15 W, 45 W, MAX

[LINE OUT]

GND LIFT switch

[SPEAKER OUT]

IMP.SELECT switch
4 ohm/8 ohm, 16 ohm

Indicators

CLEAN CHANNEL
BOOST
TONE
CRUNCH CHANNEL
BOOST
TONE
EFX LOOP A
EFX LOOP B
POWER

Connectors

INPUT HIGH/LOW jack: 1/4-inch phone type
LINE OUT jack: 1/4-inch phone type
LINE OUT jack: XLR type
PHONES jack: Stereo 1/4-inch phone type
FOOT SW (TIP: EFX LOOP A, RING: EFX LOOP B) jack: 1/4-inch TRS phone type
FOOT SW (TIP: CH SELECT, RING: DUAL TONE) jack: 1/4-inch TRS phone type
FOOT SW (GA-FC) jack: 1/4-inch TRS phone type
EFX LOOP A SEND jack: 1/4-inch phone type
EFX LOOP A RETURN jack: 1/4-inch phone type
EFX LOOP B SEND jack: 1/4-inch phone type
EFX LOOP B RETURN jack: 1/4-inch phone type
REC OUT port: USB type B
MIDI IN jack
SPEAKER OUT jack
AC IN jack

Power Consumption

108 W

Accessories

Owner’s manual
Power cord
Speaker Connection Cable
GA-FC sticker

Options (sold separately)

Footswitch (BOSS FS-5L, BOSS FS-6, BOSS FS-7)
GA Foot Controller (GA-FC)

Size and Weight

Width

545 mm
21-1/2 inches

Depth

233 mm
9-3/16 inches

Height

234 mm
9-1/4 inches

Weight

8.0 kg
17 lbs 11 oz
