LD Systems SAT 262 G2 2 × 6,5inch Passive Installation Speaker

Spesifikasi LD Systems SAT 262 G2 2 × 6,5inch Passive Installation Speaker

LD Systems SAT 262 G2 2 × 6,5inch Passive Installation Speaker

With its slim, streamlined design, the LD Systems SAT 262 G2 is excellently suited for permanent installation and discreet integration in virtually any setting. It features two 6.5″ custom woofers and a 1” Celestion compression driver connected to a rotating CD horn with 80° x 60° dispersion. This makes the passive 2-way speaker ideal for both vertical and horizontal use. The SAT 262 G2 attains a maximum sound-level pressure of 116 dB over a frequency response curve of 65–19 kHz with a permanent load capacity of 180 watts. The reflex casing made of 12 mm MDF has four M8 mounting holes. The inputs are a speakON-compatible socket and a terminal block, while an additional terminal block serves as an output for convenient parallel connection.

Special wall holders are available as an accessory to facilitate wall mounting. The SAT 262 G2 is available in black (Art. No. LDSAT262G2) or white textured finish (Art. No. LDSAT262G2W).

General Specification

• Product type Installation Loudspeakers
• Type Wall-mounted Loudspeaker
• Low/mid driver dimensions 2 x 6.5 ”
• Woofer size 2 x 165.1 mm
• Woofer magnet Ferrite
• Woofer brand Custom-made
• Woofer voice coil (mm) 38.1 mm
• Horn CD horn
• HF driver dimensions 1 ”
• HF driver size 25.4 mm
• HF driver magnet Ferrite
• HF driver brand Celestion
• HF driver voice coil 1 ”
• HF driver voice coil 25.4 mm
• Dispersion (H x V) 80 x 60 °
• Load rating (RMS) 180 W
• Peak power 360 W
• Frequency response 65 – 19000 Hz
• SPL (1W/1m) 93 dB
• Max. SPL 116 dB
• Impedance 8 Ohm(s)
• Protection circuits HF Driver
• Loudspeaker inputs 2
• Speaker input connections Speakon compatible, Terminal block
• Loudspeaker outputs 1
• Speaker output connections Terminal block
• Speakers per amplifier channel (DSP44/45K) 4
• Cabinet material 12 mm MDF
• Cabinet surface texture paint
• Cabinet colour Black
• Cabinet construction Bass Reflex
• Width 200 mm
• Height 630 mm
• Depth 205 mm
• Weight 9,8 kg
