Spesifikasi JBL PRX 315D 15 inch 2 way Passive Stage Monitor

JBL PRX 315D 15 inch 2 way Passive Stage Monitor

Speaker System For Live Performance

For the low ends, PRX315D uses a premium 15-inch low frequency driver with a edge-wound ribbon voice coil of 2 ½ inch (64mm) in diameter to bring the system solid bass, high efficiency and large power handling capabilities. A JBL 2412 1-inch ferro-fluid cooled compression driver with titanium diaphragm provides the system with clean and warm high notes and uncompromised reliability. JBL SonicGuard™ technology improves system stability by protecting the high frequency driver from excessive power without interrupting the show. Apart from the drivers, fault-free performance of the system also relies on the precision-crafted crossover network, which feeds the two drivers with clear cut frequencies with minimum overlap and is capable of handling high power with its high-voltage capacitors and inductors. The patented Progressive Transition™ waveguide mounts on top of the tweeter and provides the system with superior coverage control, reduced distortion and smoother frequency response.

PRX315D encloses all the acoustic components in a rugged cabinet constructed from 15mm MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low frequency response. Two all-steel handles are integrated to sides of the case to make transport and setup easier. A 36-mm socket allows PRX315D to be mounted on a speaker pole and to work as a main or fill. The socket supports either up-straight standing or 10° tilting, helpful when the audience coverage needs to be uniformed. For the front of the speaker, a dent-resistant grille made from 18-gauge perforated steel protects the components inside from damage on the move or during the show.

Product Description
It makes things loud and clear. Great for parties or big spaces
You can control it easily without being a tech expert. Just plug in and play
It's not too heavy and has handles, so you can move it around without much trouble
You can connect it to different devices like microphones or music players without any problem
It's built tough, so it can handle a bit of rough use without breaking

• System Type 15” 2-way speaker
• Frequency Range (-10dB) 38 Hz – 16 kHz
• Frequency Response (±3 dB) 50 Hz – 12.5 kHz
• Sensitivity 98 dB SPL
• Nominal Impedance 8 Ω
• Power Capacity 250 watts
• Peak Power Capacity 1000 watts
• Recommended Amplifier Power 250 - 500 watts @ 8Ω
• Maximum SPL (1m) 128 dB
• Nominal Dispersion 90° × 50°
• Crossover Frequency 1.6 kHz
• Dimensions (H x W x D) 681 mm × 455 mm × 422 mm(26.8 in × 17.9 in × 16.6 in)
• Net Weight 23.9 kg (52.7 lbs)
• Shipping Weight 29.1 kg (64.2 lbs)
• HF Driver JBL 2412 1” exit compression driver mounted on Progressive TransitionTM Waveguide
• LF Driver JBL M115-8A
• Input Connector Parallel Neutrik Speakon® NL-4 (×1)；1/4” TS phone jack (×1);
• ENCLOSURE CONSTRUCTION 15 mm (0.6 in) MDF (Medium Density Fiberboard) with glued and mechanically fastened joint detail; black painting.
• Grille 18-gauge, powder-coated steel
• Mounting & Suspension 36 mm, dual-angle pole-mount socket; 12×M10 suspension points
