Spesifikasi JBL JRX215 15"
JBL JRX215 15"
Full range JBL on a budget.
This trapezoidal, 15" speaker system is at home in live sound, dance music and speech reinforcement.
- JBL 15 in low frequency driver with a 2." diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling
- JBL 2414H-C 1" polymer diaphragm compression driver improves high frequency performance as well as system reliability
- The advanced network topology crossover design shapes the frequency response to deliver coherent summation in the crossover region
- High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating
- Progressive Transition high frequency waveguide provides superior coverage control, reduced distortion, and smoother frequency response
- The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in ) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance
- SonicGuard protects the high frequency driver from excess power without interrupting the performance
- Non-resonant, all-steel handles are used
- Attractive 18-gauge perforated, steel grille protects components from damage
Order now and get the JBL sound at a price that won't starve the band.
JRX215 15 two-way passive loudspeaker system with 1000W peak power handling
- Power Rating: 250 W / 1000W
- Frequency Range (-10 dB): 38 Hz - 16 kHz
- Frequency Response (±3 dB): 50 Hz - 12.5 kHz
- Sensitivity (@1m): 98 dB SPL
- Nominal Impedance: 8 ohms
- Recommended Amplifier Power: 250 W to 500 W into 8 ohms
- Maximum SPL: 128 dB
- Nominal Dispersion: 90º x 50º
- Crossover Frequency: 1.6 kHz
- (H x W x D): 27.5" x 18.1" x 17"
- Weight: 61 lb
- High Frequency Driver: JBL 2414H-C 25mm (1 in) polymer diaphragm compression driver mounted on Progressive Transition Waveguide
- Low Frequency Driver: JBL M115-8A
- Input Connectors: Neutrik Speakon NL-4 (x1); .25in TS phone jack (x1); parallel
