Spesifikasi JBL PRX 312MD 12 inch 2 way Passive Stage Monitor
JBL PRX 312MD 12 inch 2 way Passive Stage Monitor
Installable Portable PA Speakers
Product Description
- 12-inch portable two-way speaker system designed for stage monitoring at live performance or speech.
- PRX312MD encloses all the acoustic components in a rugged cabinet constructed from 15mm
- Capable of handling high power with its high-voltage capacitors and inductors.
- 1-inch ferro-fluid cooled compression driver with titanium diaphragm provides the system
-
Specifications
System Type 12” 2-way stage monitor
Frequency Range (-10dB) 60 Hz – 16 kHz
Frequency Response (±3 dB) 70 Hz – 12 kHz
Sensitivity 99 dB SPL
Nominal Impedance 8 Ω
Power Capacity 250 watts
Peak Power Capacity 1000 watts
Recommended Amplifier Power 250 - 500 watts @ 8Ω
Maximum SPL (1m) 129 dB
Crossover Frequency 1.8 kHz
Coverage 90° × 50°
Dimensions (H x W x D) 567 mm × 381 mm × 323 mm (22.3 in × 15.0 in × 12.7 in)
Net Weight 16.7 kg (36.8 lbs)
Shipping Weight 20.3 kg (44.8 lbs)
HF Driver JBL 2412 1” exit compression driver mounted on Progressive TransitionTM Waveguide
LF Driver JBL M112-8
Input Connector Neutrik Speakon® NL-4 (×1);1/4” TS phone jack (×1); parallel
ENCLOSURE CONSTRUCTION 15 mm (0.6 in) MDF (Medium Density Fiberboard) with glued and mechanically fastened joint detail; black painting.
Grille 18-gauge, powder-coated steel
Mounting & Suspension 36 mm, dual-angle pole-mount socket; 9×M10 suspension points
