Spesifikasi Ibanez TQM1-NTF Tom Quayle Signature Electric Guitar

Ibanez TQM1-NTF Tom Quayle Signature Electric Guitar

In typical Ibanez fashion, the Tom Quayle signature model has a bolt-on construction, ensuring optimal note definition and snap. For a player like Quayle, this is essential for his signature fast legato runs, where an immediate response and feel is necessary. The sculpted neck join makes access to the upper end of the fretboard a breeze, all the way up to the 22nd fret.

Formed of an Alder body, this tonewood ensures a full-bodied and balanced tone, with a warm low-end and plenty of upper mid-range clarity. Adorned with a gorgeous Monkeypod top, the TQM1-NTF is sure to inspire you pick it up and play for hours on end.

The roasted Maple neck and fretboard is an incredible aspect of this guitar, offering a bright sound and amazing tuning stability. The roasting process removes all moisture from the wood, making it more durable and less susceptible to warping in differing climates or environments. So, you can feel assured that this guitar will rarely need setting up, and if you're a touring musician this is an incredible perk!

Fitted with jumbo frets, this neck lends itself to fast Quayle-style lead playing, with the large frets letting you bend strings and add vibrato almost effortlessly. Made of stainless steel, these frets won't wear as quickly compared to more traditional materials, ensuring brilliant longevity.

Electronics and Hardware

The TQM1-NTF is fitted with a set of Seymour Duncan Hyperion pickups, made exclusively for the AZ series. Providing plenty of output, these pickups are incredibly versatile and appropriate for a range of styles, not just jazz or blues. The dyna-MIX9 pickup switching system allows you to access 9 different configurations, with the mini-switch between the volume and tone controls allowing you to engage humbucker or single-coil modes.

Timeless chrome hardware keeps this instrument classy and elegant, with the Gotoh T1802 tremolo letting you perform divebombs or gentles warbles for sweet-sounding chords. Paired with a set of Gotoh Magnum-Lock machine heads, this guitar will stay in tune amazingly well, even after plenty of tremolo abuse.

Here's what Ibanez say about the TQM1-NTF Tom Quayle Signature Guitar:

S-TECH WOOD Roasted Maple 1pc neck

S-TECH special roasted treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes. The neck is sealed with an oil finish which helps make it feel similar to a well-played guitar neck.

S-TECH WOOD Roasted Maple Fretboard

S-TECH special roasted treatment provides a superior attack and a well-balanced tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.

Super All Access Neck Joint

The Super All Access Neck Joint offers superior playability with its 8mm concave curve from the body top to the spherical surface of the joint area. By maximizing the joint area between the body and the neck, sustain and resonance are increased as well.

Luminescent side dot inlay

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Gotoh® Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)

The AZ comes with GOTOH® MAGNUM LOCK® machine heads, which have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.

Oil-impregnated Bone nut /Stainless Steel Frets

The Oil-impregnated bone nut provides superior tuning stability and warm rich resonance. Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.

Seymour Duncan® Hyperion™ Pickups

Seymour Duncan® Hyperion™ Pickups feature a moderate output through Alnico-5 magnets to keep the clarity of the fundamental tone when using a distortion sound, and to deliver a clear pick attack. From treble to bass, the overall tonal balance is evenly adjusted., and works well with various effect pedals.

Dyna-MIX 9 switching system w/Alter switch

Dyna-MIX 9 offers nine sound variations, and can easily switch between humbucker and single coil modes with just the mini switch. One mode is even able to simulate a humbucker sound from the combination of the 2 single coil pickups.

Ibanez T1802 synchronized bridge (Made by Gotoh®)

T1802 tremolo bridge features machined titanium saddles and a machined steel tremolo block for a quick response, thick lows and rich highs.
The 10.5mm string spacing allows for easy picking across strings. Its snap-in construction makes it easy to load a tremolo arm.

Specifications

• Neck type: TQM S-TECH WOOD Roasted Maple neck
• Body: Monkeypod top/Alder body
• Fretboard: S-TECH WOOD Roasted Maple fretboard w/Abalone dot inlay & Luminescent side dot inlay
• Frets: Jumbo Stainless Steel frets
• Bridge: Gotoh® T1802 tremolo bridge
• Neck pickup: Seymour Duncan® Hyperion™ (S) neck pickup (Passive/Alnico)
• Middle pickup: Seymour Duncan® Hyperion™ (S) middle pickup (Passive/Alnico)
• Bridge pickup: Seymour Duncan® Hyperion™ (H) bridge pickup (Passive/Alnico)
• Electronics: Dyna-MIX9 switching system w/Alter Switch
• Factory tuning: 1E, 2B, 3G, 4D, 5A, 6E
• String gauge: .010/.013/.017/.026/.036/.046
• Nut: Bone nut
• Machine Heads: Gotoh® MAGNUM LOCK w/H.A.P.
• Hardware color: Chrome
