HK AUDIO Lucas Nano 305FX Portable Sound System

Spesifikasi HK AUDIO Lucas Nano 305FX Portable Sound System

HK AUDIO Lucas Nano 305FX Portable Sound System

The HK Audio Lucas Nano 305FX is a compact, portable 2.1 stereo PA speaker system that consists of an 8-inch subwoofer alongside two 3.5-inch satellite speakers and comes equipped with an integrated 5-channel mixer as well as Bluetooth connectivity and a wealth of built-in effects. The compact, lightweight system is perfect for a wealth of applications such as small acoustic sessions, mobile DJs, karaoke, house/garden parties, gym classes, schools and colleges, conferences, and small venues.

The Lucas Nano 305FX is a genuine all-rounder thanks to the impressive sound and wealth of controls and inputs that allow you to connect to all kinds of audio equipment and get the best sound possible. The 8-inch subwoofer comes equipped with a custom-made Celestion 8-inch low-frequency driver and delivers a frequency response of 44 Hz – 190 Hz. The two satellite speakers come fitted with Celestion custom-made 3.5-inch mid-high frequency drivers that deliver a frequency response that ranges from 190 Hz – 20 kHz. Both the satellite speakers and subwoofer work in perfect harmony to give you a full range sound with loads of power.

The speaker system comes fitted with a built-in 5-channel mixer that features three ¼-inch TRS Jack/XLR combo inputs for instruments and microphones as well as a 3.5mm auxiliary input for audio devices and dual ¼-inch TRS Jacks for channels 4 and 5 which can be used as a single stereo input for mixers. There is also Bluetooth connectivity which allows you to connect your smartphone or tablet to the system wirelessly. Channels 1 and 2 feature +48v phantom power for powering condenser microphones while dual ¼-inch TRS Jack outputs allow you to connect to the satellite speakers. There is a ‘Thru’ output that enables you to connect another speaker system giving you the ability to daisy chain multiple speakers together.

The mixer comes complete with volume controls for each input while channels 1-3 feature 2-band EQ controls for adjusting the sound as you please. All inputs and outputs are fitted with a volume control, so you can get the best sound possible. The mixer is equipped with a built-in Digital Signal Processor that provides you with several reverb effects allowing you to create spatial effects so your vocals and instruments will sound larger and smoother. The Lucas Nano 305FX system can produce an impressive Sound Pressure Level of 120dB which means this speaker set has the best sound-to-volume ratio on the market.

An intelligent design makes the Nano 305FX system extremely portable and lightweight weighing only 10.3kg, you can easily carry the whole system with one hand. The satellite speakers fit perfectly into a transport bay inside the subwoofer and also means you can assemble the speaker system within seconds. Each of the speakers comes equipped with a polypropylene textured coated finished that ensures durability and protects against accidental impact damages. The speakers feature a highly-robust build that makes sure the system will withstand everyday on-stage use. For peace of mind, the Lucas Nano 305FX comes equipped with a five-year warranty which is activated once you’ve registered the system.

HK Audio Lucas Nano 305FX Portable Active PA Speaker System Key Features:

• Active, multifunctional PA system
• Integrated 5-channel mixer
• Bluetooth Audio Streaming
• 7 on-board reverb effects
• Two-band EQ for channels 1-3
• Phantom power for channels 1-2
• Optimized for use as a 2.1 Stereo system
• Can be extended into a more powerful Twin Stereo System setup when used in conjunction with any other 300 series LUCAS NANO
• Functions as an elegant Mono PA
• Active 8” high-performance subwoofer
• 2 satellites with 3.5″ broadband woofers
• All speakers custom-made by Celestion
• 750-watt peak power (calc.)
• 120 dB max. SPL
• Low-ranging bass down to 44 Hz
• Weighs just 10.3 kg
• Satellite transport bay inside the subwoofer enclosure
• Simple handling; assembles in seconds
• High quality STEREO STAND ADD-ON from König & Meyer (available separately)
• Height-adjustable, signal-carrying S-CONNECT POLE LN (available separately), for cable-free setup as Mono or Twin Stereo System setup
• Designed and engineered in Germany
• Five-year warranty (after registration)

​

HK Audio Lucas Nano 305FX Portable Active PA Speaker System Technical Specifications:

LUCAS NANO 305 FX System

• Product Class Portable stereo PA system
• Audience: Up to 80
• Frequency response: -10 dB 44 Hz – 20 kHz
• Power Rating: 230 W (RMS)
• Peak power (calc.): 750 W
• Amplifier: Class D
• Active protection circuits: MulitBand limiter, Subsonic filter, Thermo protection, Overload protection
• Enclosure: Surface-coated Polypropylene
• Optional accessories: Stereo Stand Add-on, S-Connect Pole LN, Add-on Package Two, Roller Bag, Link-Kabel
• Weight: 10.3 kg


LUCAS NANO 300 Series Satellite

• Max SPL: peak 120 dB (Satellite Array)@10%THD, Halfspace
• Frequency response: -10 dB 190 Hz – 20 kHz
• Mid/High Speaker 3.5" Broadband (Celestion custom-made)
• Mid/high unit dispersion pattern, horizontal/vertical 60° x 40° (Single Satellite),
• 60° x 30° (Satellite Array)
• Pole mount: 3/8" thread
• Dimensions (WxHxD cm): 13 x 13 x 11.5
• Weight: 1 kg


LUCAS NANO 305 FX Subwoofer

• Max SPL: peak 118 dB@10%THD, half space
• Frequency response: -10 dB 44 Hz – 190 Hz
• LF Speaker: 8" Celestion custom-made
• Inputs: 3 x Combination 1/4" (6.3 mm)/XLR Ports, 2 x 1/4" (6.3 mm) Jacks/Stereo Mini-Jack, Bluetooth In, Link In (for Twin Stereo Mode)
• Outputs Speaker Out, Easy-Click, Rec Out,Link Out for Twin Stereo Mode
• Special Features: 5-Channel Mixer, 2-Band EQ for Channels 1-3, 7 Reverb Eff ects, Bluetooth Audio Streaming
• Pole mount: M33 for the (signal-routing) S-CONNECT POLE LN, a speaker pole adapter sleeve (M33 to M20) is included
• Dimensions (WxHxD cm): 30 x 39 x 42
• Weight: 8.3 kg
