Camera Configuration

• Handy Video Recorder
• 1/3-Inch 3 Megapixel CMOS Sensor
• Fixed Focus Lens Design
• 160° Wide-Angle Lens
• F2.0 Aperture Lens
• Portable Handheld Design
• One-Touch Recording System
• Color LCD Display

Video System

Video Resolution

• Full HD 1080p @ 30 fps
• Full HD 1080p @ 24 fps
• HD 720p @ 30 fps
• HD 720p @ 24 fps
• MPEG-4 AVC / H.264 Recording Format
• MOV Video File Format

Lens Specifications

• 160° Ultra Wide-Angle Lens
• F2.0 Aperture
• Approx. 16.6 mm Focal Length (35 mm Equivalent)
• Fixed Focus Design
• Focus Range: 36 cm To Infinity
• Excellent Coverage For Solo Performers And Bands

Audio Recording System

Built-In Microphones

• Stereo X/Y Condenser Microphones
• 120° X/Y Microphone Configuration
• Professional Stereo Imaging
• High SPL Recording Capability
• Optimized For Music Recording
• Natural Stereo Sound Capture

Audio Performance

• Maximum Audio Resolution: 24-Bit / 96 kHz
• WAV Audio Recording Format
• Maximum SPL: 120 dB SPL
• Low Distortion Recording
• Wide Dynamic Range
• Studio-Quality Audio Capture

Recording Modes

Video + Audio Recording

• Simultaneous HD Video And Audio Recording
• MOV Format Recording
• Direct Recording To microSD Card
• Optimized For Live Performance Capture

Audio-Only Mode

• Standalone Audio Recorder Function
• WAV Format Recording
• Suitable For Rehearsals And Music Demos
• Extended Recording Capability

Scene Presets

Built-In Scene Modes

• Auto
• Outdoor
• Sunset
• Night
• Concert Light
• Concert Lo-Lit
• Concert Hall
• Jazz Club
• Dance Club
• Rehearsal Studio
• Garage

Exposure Optimization

• Automatic Lighting Adjustment
• Optimized For Stage Lighting
• Improved Low-Light Performance
• Quick Preset Selection

Field Of View Settings

• 0.75×
• 0.85×
• 1.00×
• 1.30×
• 1.50×

Benefits

• Flexible Framing Options
• Suitable For Solo Artists
• Suitable For Full Band Recording
• Adaptable To Different Distances

Audio Controls

Gain Control

• Adjustable Input Gain
• Analog-Style Level Control
• On-Screen Metering
• Auto Gain Function

Filters

• Low-Cut Filter Off
• 80 Hz Low-Cut
• 120 Hz Low-Cut
• 160 Hz Low-Cut
• Reduces Handling Noise And Rumble

Connectivity

Audio Connections

• 1 × 3.5 mm Stereo External Input
• Plug-In Power Support
• External Microphone Compatible

Monitoring Output

• 1 × 3.5 mm Stereo Headphone Output
• Line Output Function
• Real-Time Monitoring Capability

Video Output

• 1 × HDMI Micro Type-D Output
• HDTV Playback Support

USB Connectivity

• USB 2.0 Micro-B Port
• Card Reader Mode
• USB Microphone Mode
• Webcam Mode
• Live Streaming Support

Storage System

Supported Media

• microSD Card
• microSDHC Card
• microSDXC Card
• Class 10 Or Higher Recommended
• Capacity Up To 128 GB

Display

• 1.77-Inch Full Color LCD
• Resolution: 160 × 128 Pixels
• Live View Monitoring
• Menu Navigation Interface
• Playback Function

Streaming & USB Features

Webcam Mode

• Computer Webcam Function
• Live Streaming Ready
• USB Audio Support
• Compatible With Streaming Software

USB Microphone Mode

• USB Audio Interface Function
• 44.1 kHz / 16-Bit Audio
• Podcast Recording Ready
• Online Meeting Ready
