Behringer AMP800 V2 Ultra-Compact Headphone Amplifier

Behringer AMP800 V2 Ultra-Compact Headphone Amplifier

Specifications

• Model: Behringer AMP800
• Link Output A: 1/4″ TRS Connector, Balanced
• Frequency Response: 10Hz – 120kHz, -3dB
• Dynamic Range: 108dB, 10Hz to 22kHz (100? Load)
• Distortion: 0.007 Typical (100? Load)
• Crosstalk:
• Signal-to-Noise Ratio: 10Hz to 22kHz
• Maximum Output Level: +21dBm / 124mW (100Ω Load)
• Minimum Output Impedance: 47Ω
• Power Supply: External Power Supply, 9V /750mA
• Power Consumption: 11W
• Dimensions: 48mm x 242.6mm x 120mm / 1.89″ x 9.55″ x 4.72″ (H x W x D)
• Weight: 0.77kg / 1.7lbs

Inputs

• Connector: 1/4″ TRS, Balanced
• Impedance:
  • Balanced: 20kΩ
  • Unbalanced: 10kΩ
• CMRR: 40dB Typical @ 1kHz

Phones Output

• Connector: 1/4″ TRS, Stereo
• Impedance: Min. 100Ω
• Maximum Output Level: +13dBu @ 100Ω Load
