Allen & Heath CQ 20B Ultra Compact Digital Mixer with Wi-Fi

Allen & Heath CQ 20B Ultra Compact 20 In / 8 Out Digital Mixer with Wi-Fi

Spesifikasi Utama

Type: Ultra-Compact Digital Mixer
Model: CQ-20B
Brand: Allen & Heath
Input Channels: 20 Inputs to Mix (16 Mono/Linkable + 4 Stereo)
Outputs: 8 Outputs (Main L/R + 6 Aux)
Mic/Line Input: 16 (8 XLR + 8 XLR/TRS Combo, 2 Hi-Z)
Processing: 96 kHz FPGA Processing
Effects: 4 Stereo FX Engines
Audio Interface: USB-B 24×24 @ 48/96 kHz
Recording: SD Card Multitrack, USB-A Stereo Record/Playback
Wireless: Built-in Dual-Band Wi-Fi (2.4/5 GHz) & Bluetooth 4.1
Network: RJ45 Ethernet
Dimensions: ±372 × 154 × 134 mm
Weight: ±2,6 kg

Fitur

• 96 kHz FPGA audio processing.
• Built-in dual-band Wi-Fi.
• Bluetooth audio playback.
• Gain Assistant otomatis.
• Feedback Assistant hingga 16 filter per output.
• 4 Stereo FX Engines.
• USB Audio Interface 24×24.
• SD Card multitrack recording.
• Automatic Mic Mixer (AMM).
• Kontrol melalui Windows, macOS, iOS, dan Android.

Performa

Allen & Heath CQ-20B menghasilkan kualitas audio profesional dengan workflow yang praktis tanpa kontrol fisik. Berkat Wi-Fi bawaan, mixer dapat dikendalikan dari tablet, smartphone, atau komputer, menjadikannya ideal untuk aplikasi panggung, instalasi tetap, maupun recording portabel.

Konektivitas

• 8 × XLR Mic/Line Input
• 8 × XLR/TRS Combo Mic/Line Input
• 2 × Stereo TRS Line Input
• 2 × XLR Main Output
• 6 × XLR Aux Output
• 2 × TRS Alt Output
• Headphone Output
• USB-B 24×24 Audio Interface
• USB-A Record/Playback
• SD Card Slot
• RJ45 Ethernet
• Built-in Wi-Fi
• Bluetooth
• Dual Footswitch Input

Kelengkapan

• 1 Unit Allen & Heath CQ-20B
• IEC Power Cable
• User Manual
