Yamaha XMV4140D 4 Channel 140 watt Power Amplifier with Dante

Spesifikasi Yamaha XMV4140D 4 Channel 140 watt Power Amplifier with Dante

Yamaha XMV4140D 4 Channel 140 watt Power Amplifier with Dante

The Power Amp for Commercial Spaces

Halls, malls, banquet rooms, and other commercial spaces demand a lot of speaker-driving energy, so it’s important to have a powerful unit like the Yamaha XMV4140-D 4-channel 140W Power Amplifier with Dante backing your system. This 4-channel Class-D power amp is efficient, flexible in connection and configuration, and comes ready to integrate into any existing 2U rack space. Its driving power accommodates both low- and high-impedance speaker systems at the same time, and even offers Double Power Mode for driving seriously high-output systems. Easily chain the XMV4140-D with your other Yamaha install audio system devices such as the MTX Series of processors, too. Smart redundant functions, versatile source selections, internal protection features — the XMV4140-D covers all the bases with ease. And with its Dante virtual audio network compatibility, the XMV4140-D easily accommodates extra-large spaces that require long-distance cabling. Designing an audio system for a commercial space? Sweetwater pros recommend having the Yamaha XMV4140-D Power Amplifier with Dante at the foundation!

Unparalleled efficiency
From banquet presentations to multi-room commercial setups, the XMV4140-D is engineered with innovative and professional-grade circuitry with impressive operational capabilities. Yamaha’s patent-pending output voltage-matching circuit works in conjunction with its highly-efficient Class D circuitry to bring the XM4140’s outbound efficiency to over 90%. Its automatic switching engages the lower voltage drive for low-impedance operation to avoid drastic energy loss, maintaining an efficient workflow while performing with impeccable clarity. Armed with Power Factor Correction in its power supply, the XMV4140-D delivers harmonically balanced audio at lower currents without effecting its output intensity.

No breaker shutdowns or heavy and bulky cabling is required! Understandably, every application isn’t going to be equal — you’ll need to run both high- and low-impedance connections within the same space at times that would ordinarily require the use of varying amps and transformers. Luckily, the XMV4140-D can handle both impedances, even at the same time, enabling both streamlined system linking and much simpler installation. This power amp not only accommodates high-impedance, 70V/100V (125W) line-level connections and low-impedance, 4-ohm/8-ohm (140W) connections at the same time, but offers assignability for 70V and 100V modes to channel pairs without inhibiting the total number of available outputs — eliminating the need for bridge mode channel combinations!

Working smarter and harder
Detecting and preventing roadblocks in your system carries over to the XMV4140-D’s dual redundant functions: Backup mode and Override mode. In Backup mode, this power amp will automatically switch to analog inputs when incoming digital input interruptions are detected, with the brains to return to the digital input once the original source is recovered. The other side of the coin is Override mode, which switches input sources within a channel — free of interruptions — when a voice input from any analog input is detected. Either way, the XMV4140-D will always have your back.

Features:

• Ideal 4-channel power amplifier for commercial installations like malls, banquet halls, and more
• Patent-pending output voltage-matching circuit and Class-D circuitry supply over 90% efficiency
• Automatic switching to low voltage drive prevents massive energy loss
• Power Factor Correction delivers harmonically balanced audio at lower currents
• Simultaneous 140W low- (4-ohm/8-ohm) and 125W high- (70V/100V) impedance operation creates output versatility and easy installation
• Assignability for 70V and 100V modes to channel pairs eliminates the need for bridge mode channel combinations
• Double Power Mode doubles the output of your channel to work easily with high-output speaker systems
• Engineered automatic protection functions prevent overheating, overcurrent, and low-load impedance, and more
• Backup mode allows the power amp to switch to analog inputs once digital input interruptions are detected
• Override mode switches input sources when voice inputs from analog inputs are detected without interruption
• Enabled per-channel selection of digital and analog Euroblock inputs
• Dante-equipped for larger spaces that require excess cabling, supports AES67 audio network
• Dante enables Ethernet linking and AMX/Crestron controlling
• Dante Domain Manager and Device Lock keep your Dante infrastructure protected
• Works incredibly well with separate MTX and MRX processors
• Computer adjustments enabled through the MTX-MRX Editor app, PV Touch, PV Control, and PV Amp Editor
• Fits standard 2U rackspace
•
